Fast & Reliable Data Cables for Seamless Connections
Data Cables – Cat 5E
UNSCREENED TWISTED PAIR (UTP) CABLES – DATA CABLE:
This cable meets or exceeds the requirements of TIA/EIA 568-B.2 and ISO/IEC 11801. Suitable for transmission of high speed data, digital and analogue voice and video (RGB) signals on LAN’s. Support Gigabit Ethernet (1000 baseT) standard.
CONSTRUCTION :
Cable Type: Cu / PVC
Conductor: 24 AWG solid bare copper
Insulation: Polyethylene
Pairs:
2 insulated conductors twisted together, lays varied to minimise crosstalk
4 pairs twisted together
Sheath:
PVC (Grey,Orange, Blue) or LSOH (Violet), 6.35mm overall diameter maximum. Other colours available on request.
COLOUR CODES :
Pair 1: Conductor 1 – Blue & Conductor 2 – White / Blue
Pair 2: Conductor 1 – Orange & Conductor 2 – White / Orange
Pair 3: Conductor 1 – Green & Conductor 2 – White / Green
Pair 4: Conductor 1 – Brown & Conductor 2 – White / Brown
CONNECTION SYSTEMS:
Compatible with all common systems according to EN 50173, ISO/IEC 11801 and TIA/EIA 568-B
ELECTRICAL PROPERTIES:
Conductor Resistance: < 9.38 O/100m
Mutual Capacitance: < 5.6 nF/100m
Resistance Unbalance: 3% maximum
Capacitance Unbalance: 330 pF/km
Delay Skew: < 45 ns
NVP: 68%
MECHANICAL PROPERTIES:
Bending Radius
During Installation: > 42 mm
After Installation: > 21 mm
Pulling Force: < 65 N
Temperature Range : -15OC +/-70OC
Heat of Combustion : 373 MJ/km
PACKAGING:
Available in easy-pull boxes (305m) or non-returnable reels of longer lengths.
Data Cables – Cat 6
UNSCREENED TWISTED PAIR (UTP) CABLES – DATA CABLE:
This cable meets or exceeds the requirements of TIA/EIA 568-B.2 and ISO/IEC 11801. Suitable for transmission of high speed data, digital and analogue voice and video (RGB) signals on LAN’s. Support Gigabit Ethernet (1000 baseT) standard. The X-Seperator at the center ensures Cat 6 performance
CONSTRUCTION:
Cable Type: Cu / PVC
Conductor: 0.56mm solid bare copper
Insulation: Polyethylene
Pairs:
2 insulated conductors twisted together, lays varied to minimise crosstalk
4 pairs twisted together
Sheath:
PVC (Grey,Orange, Blue) or LSOH (Violet), 6.35mm overall diameter maximum. Other colours available on request
COLOUR CODES:
Pair 1: Conductor 1 – Blue & Conductor 2 – White / Blue
Pair 2: Conductor 1 – Orange & Conductor 2 – White / Orange
Pair 3: Conductor 1 – Green & Conductor 2 – White / Green
Pair 4: Conductor 1 – Brown & Conductor 2 – White / Brown
CONNECTION SYSTEMS:
Compatible with all common systems according to EN 50173, ISO/IEC 11801 and TIA/EIA 568-B
ELECTRICAL PROPERTIES:
Conductor Resistance: 141 O/100m
Mutual Capacitance: 49 pF/km (nom.)
Resistance Unbalance: 2% maximum
Capacitance Unbalance: 1600 pF/km
Delay Skew: 400 ns/km
NVP: 68%
MECHANICAL PROPERTIES:
Bending Radius
During Installation: > 8xD
After Installation: > 4xD
Pulling Force: 100 N
Temperature Range : -15OC +60OC
Heat of Combustion : 373 MJ/km
PACKAGING:
Available in easy-pull boxes (305m) or non-returnable reels of longer lengths.
USB Data Cord in UAE
Acrab Cab is a trusted manufacturer and supplier of data cables, serving residential, commercial, industrial, and technology requirements with dependable products engineered for consistent performance. With extensive industry experience and a strong presence in the UAE market, we deliver reliable data transfer cable solutions designed to support fast, stable communication across diverse modern applications today.
Our commitment extends beyond manufacturing quality products. As a dependable data transfer cable supplier, we focus on delivering connectivity solutions that combine speed, durability, signal integrity, and dependable construction for demanding environments. Every product is developed to support contractors, consultants, distributors, and businesses with practical solutions suited for data communication projects throughout the region.
From everyday device connections to large-scale network installations, Acrab Cab continues to provide dependable data solutions through quality-focused manufacturing, efficient supply capabilities, and customer-oriented service that supports long-term project success across the UAE.
Copper Data Cables
Manufactured with quality copper conductors, these cables support reliable data transmission, stable connectivity, and consistent network performance. Their practical construction makes them suitable for offices, commercial buildings, communication systems, and structured network installations requiring dependable data transfer.
Ethernet Data Cables
Designed for network connectivity, these cables provide dependable data transmission and stable communication between connected devices. Their construction supports computers, networking equipment, offices, commercial facilities, and structured cabling systems requiring reliable and efficient network performance.
Structured Data Cables
Suitable for organised network installations, these cables provide dependable connectivity, signal integrity, and efficient data transmission. Their practical construction supports structured cabling systems across offices, commercial buildings, data networks, and communication environments requiring consistent network connections.
Network Communication Cables
Designed for modern communication systems, these cables support reliable connectivity and efficient data transfer. Their durable construction makes them suitable for computer networks, office infrastructure, commercial installations, and communication applications where stable transmission and organised cabling are required.
Powering Projects with Dependable Data Manufacturing
Every successful digital installation begins with dependable cables manufactured for speed, consistency, and long-term reliability through a reliable data cable connection supplier. Acrab Cab supports contractors and technology professionals by supplying quality cable for data transfer solutions developed for modern environments where dependable communication performance remains essential.
Our manufacturing approach emphasizes precision, material quality, and practical usability across different connectivity requirements. From high speed data cable applications to complete data communication systems, our products are designed to support efficient digital connections while maintaining dependable performance across residential, commercial, and industrial projects.
By combining engineering expertise with customer-focused service, Acrab Cab continues to strengthen its position as a reliable data cable supplier and manufacturer in commercial environments, delivering dependable products that contribute to stable networks and efficient digital connectivity throughout the UAE.
Our Cables
Choose from the best cables supplied by Acrab Cab
Building Wires
Our building wire supplier range provides high-performance, fire-resistant wiring designed for long-lasting safety and durability. We are the trusted electrical cable suppliers in UAE.
Panel Wires
Acrab Cab manufactures panel wires that meet the highest safety standards. Recognized among top cable manufacturers in Dubai, we offer flexible and easy-to-install cables.
Multicore Flexible Wires
Designed for high flexibility and superior performance, our multicore flexible wires make us the most trusted electrical cable suppliers in Sharjah and winding wire suppliers in UAE.
Low Voltage Power Cable
Our electrical power cable range ensures efficient current transmission for both industrial and commercial applications. We are the best power cable manufacturer in UAE.
Internal Telephone Cables
Our internal telephone cable wires are crafted with precision to deliver noise-free communication and long-lasting durability, giving best telecom wires in the UAE.
External Telephone Cables
Acrab Cab’s external telecom wires and cables are designed for outdoor endurance and high signal transmission, making us one of the most reliable cable suppliers in Dubai.
Drop Wires
As one of the leading binding wire suppliers in Abu Dhabi and binding wire suppliers in Dubai, our drop wires ensure optimal flexibility and reliable connectivity across telecom applications.
Jumper Wires & Equipment Wires
We perform flawlessly under demanding conditions, proving why Acrab Cab stands among the top cable manufacturing companies in UAE.
Data Cables
Our data cables ensure seamless transmission for networks, designed by one of the best cable manufacturers in UAE. High-quality, fast, and interference-free — that’s Acrab Cab quality.
Our Commitment to Better Digital Infrastructure
Acrab Cab is committed to supporting the growing demand for dependable data connectivity in modern buildings through quality manufacturing, practical product design, and reliable supply solutions. Our focus remains on delivering data cable products that contribute to fast, stable, and durable communication networks across diverse technology sectors today.
As a trusted cable manufacturer for data transfer, we continue to strengthen our capabilities through continuous improvement, customer satisfaction, and dependable product consistency. Our objective is to provide reliable connectivity solutions that help professionals build faster, more efficient, and future-ready digital communication infrastructure throughout the UAE.
Whether you require a dependable usb data cord manufacturer or complete data connectivity products for commercial developments, Acrab Cab remains dedicated to delivering quality-focused solutions that support modern technology projects with confidence and reliability.
Why Choose Acrab Cab?
Reliable Manufacturing Quality
We follow consistent manufacturing practices to deliver dependable usb data cord products that support stable connections, efficient transmission, durable construction, and dependable performance across a wide range of residential and commercial applications today efficiently.
Advanced Production Capability
Our production processes support precision manufacturing and consistent product quality, helping Acrab Cab deliver dependable high speed data cable manufacturer solutions suitable for projects requiring efficient information transfer and lasting reliability.
Extensive Industry Expertise
With broad experience across data cable applications, our team understands the practical requirements of contractors, consultants, and businesses, delivering dependable connectivity products suitable for residential, commercial, industrial, and technology developments and evolving digital infrastructure projects.
Comprehensive Product Range
We offer versatile cable data transfer solutions in multiple specifications to support diverse connectivity needs, making Acrab Cab a dependable cable data transfer supplier and manufacturer for projects requiring reliable communication and consistent product availability across industries and applications today.
Efficient Supply Support
Our customer-focused supply approach helps contractors and businesses access dependable data products within planned project schedules, supporting smooth procurement and reliable delivery for commercial connectivity requirements across the UAE smoothly.
Customer-Oriented Service
We work closely with customers to understand their project requirements and recommend suitable data cable solutions, ensuring dependable support for data cable connection, customised supply needs, and long-term business relationships built on trust.
